Zipper Tilting Saw ZI-WP500TN

Product Highlights Zipper Tilting Saw ZI-WP500TN

• robust steel construction
• incl. large 505 mm-ø saw blade with 40 teeth
• stable and large carriage
• log gauge (fence)
• log support extension
• tool for saw blade change
• Pre-assembled - log bed extension/chassis only to be mounted

Scope of delivery Zipper tilting saw ZI-WP500TN

• Saw blade Ø505 x 30 (40Z)

Technical data Zipper Tilting Saw ZI-WP500TN

• Motor power S6 in W: 3000 S2(15min)
• Voltage: 230 V / 50 Hz

• Installation dimensions in mm: 1015 x 740 x 915

• min. Workpiece length in mm: 250
• max. workpiece length: 1000
• max. workpiece diameter in mm: Ø 170

• Saw blade (/bore) in mm: Ø505 (/30)
• Saw blade speed in min-1: 2800

• Sound power level in dB(A): 115
• Sound pressure level in dB(A): 101

• Gross weight in kg: 82
• Net weight in kg: 56.60

• Packing width in mm: 770
• Packing length in mm: 788
• Packaging height in mm: 1,129

• EAN Code: 9120039234410
