ELMAG PROFI TIG-WELDING INVERTER 'PFC' TIG SOUND AC-DC 2240/M

Product Highlights ELMAG PROFI TIG WELDING INVERTER 'PFC' TIG SOUND AC-DC 2240/M

TIG SOUND AC-DC 2240/M

With welding currents from 5 to 220 amperes, the TIG SOUND
AC-DC 2240/M enables precise processing of the smallest weld pools and powerful welding of thick cross-sections. A universal unit with direct and alternating current for all weldable metals.

CLAIM UP TO 24 MONTHS WARRANTY NOW!
SIMPLY REGISTER UP TO 15 DAYS AFTER DATE OF PURCHASE AT HTTPS://WWW.CEBORA.IT/GARANZIE/FRONTEND/.

Examples of use ELMAG PROFI TIG-WELDING INVERTER 'PFC' TIG SOUND AC-DC 2240/M:

Production, repair & assembly companies
Pipeline & pipeline construction
Metal, railing construction
Machine, plant & tank construction
Service & customer service

materials:
Steel
CrNi
Copper
Aluminium

Technical facts ELMAG PROFI TIG-WELDING INVERTER 'PFC' TIG SOUND AC-DC 2240/M:

• Universal use - ideal for trade and industry
• For high load operation (e.g. series production) expandable with water cooling unit
• Energy-saving PFC technology
• Welding current constant source with PFC (compliant with EN 61000-3-12)
• Reduced power consumption, high mains current tolerance
• Suitable for power generators (min. 8 kVA)
• Technical data ELMAG PROFI TIG-WELDING INVERTER 'PFC' TIG SOUND AC-DC 2240/M:
• Welding electrode diameter 1.6 mm - 4.0 mm
• Welding current setting range TIG 5 - 220 A / MMA 10 - 180 A
• 100 % duty cycle (10 min. at 40 °C) at welding current TIG 160 A / MMA 110 A
• Duty cycle (10 min at 40°C) at welding current TIG 180 A / MMA 140 A
• Duty cycle (10 min at 40°C) at max. welding current TIG 40/220 %/A / MMA 30/180 %/A
• Open-circuit voltage 47 V
• Mains connection / phases 230 / 1 V / ~
• Mains frequency 50/60 Hz
• Mains current tolerance + 15 / - 20 %
• Mains fuse slow-blow 16 AT
• Thermal overload protection Yes
• Insulation class H
• Protection class (IP) 23
• Power consumption l1 max. / l1 eff. 35/50 A
• Earth connection plug / cross-section 13 / 35 Ø / mm²
• Connection sockets 35/50 mm²
• Connection plug Schuko
• Width 207 mm
• Depth 545 mm
• Height 411 mm
• Weight 21,5 kg

Highest quality machines from ELMAG
Benefit from a 2 year ELMAG warranty

Accessories for ELMAG machines on request
