Bernardo semi-automatic sawing machine MSB 320 HGL
The MSB 320 HGL metal bandsaw is equipped with a saw frame swinging up to 60° for mitre cutting. The stepless speed adjustment and the automatic blade break control ensure user-friendly and safe operating.
Properties Bernardo semi-automatic sawing machine MSB 320 HGL
- Ideal for cutting of profiles, pipes, full rivet iron and non-ferrous materials
- This model features enhanced cutting capacity
- Automatic blade break control stops the machine if blade breaks
- Variable cutting speed for convenient operating
- Automatic, height adjustable lifting of the saw frame at cutting end with adjustable lift height
- Saw frame tilts up to 60° for mitre cutting
- Optimal cutting results due to the stepless speed adjustment
- Automatic shut-down at cutting end
- Stable saw frame, thereby smooth and vibration-free run
- Torsion-free, strong saw frame for precise cutting
Standard accessories Bernardo semi-automatic sawing machine MSB 320 HGL
- Bandsaw blade
- Material fence
- Manometer for blade tension
- Quick clamping vice
- Coolant device
- Hydraulic cylinder
- Motor protective switch
- Automatic blade break control
- Automatic shut-down
- Roller table
Technical specifications Bernardo semi-automatic sawing machine MSB 320 HGL
| Cutting capacity round / flat 90° | 320 mm / 610 x 320 mm |
| Cutting capacity square 90° | 320 x 320 mm |
| Cutting capacity round / flat 75° | 320 mm / 580 x 320 mm |
| Cutting capacity square 75° | 320 x 320 mm |
| Cutting capacity round / flat 60° | 320 mm / 510 x 320 mm |
| Cutting capacity square 60° | 320 x 320 mm |
| Cutting capacity round / flat 45° | 320 mm / 355 x 320 mm |
| Cutting capacity square 45° | 320 x 320 mm |
| Cutting capacity round 30° | 260 mm |
| Cutting capacity flat 30° | 280 x 200 mm |
| Working height | 740 mm |
| Bandsaw blade dimensions | 4160 x 27 x 0,9 mm |
| Cutting speed, stepless | 20 - 100 m/min |
| Coolant pump | 120 W |
| Motor power | 1,5 kW |
| Machine dimensions (L x D x H) | 2100 x 1200 x 1340 mm |
| Weight approx. | 1000 kg |
