Bernardo Feeding apparatus AF 308
Properties Bernardo Feeding apparatus AF 308
- Optimal to use in conjunction with small sized wood processing machines
- Complete with right and left turning device
- Rearranging the gear wheels allows for easy speed change
- Allows for individual settings for various work requirements
- Metal gearbox features hardened gear wheels
- Tiltable in any direction
- Continuous feeding speed, even at heavy load
- Complete with stand and extended bracket
Technical specifications Bernardo Feeding apparatus AF 308:
| Feeding speeds | 2,9 / 4,5 / 5,8 / 7,5 / 9 / 11,5 / 15 / 23 m/min |
| Rollers | 3 pcs. |
| Roller diameter | 100 mm |
| Roller width | 50 mm |
| Roller suspension | 24 mm |
| Motor power | 0,37 kW (0,50 HP) |
| Voltage | 400 V |
| Weight approx. | 50 kg |
