TS315F1600400V Holzmann sliding table saw incl. sizing table

Product Highlights TS315F1600400V Holzmann sliding table saw incl. sizing table

• tiltable and height adjustable circular saw blade
• 1600 mm long format sliding table with support roller at delivery
• Saw blade with Ø315mm allows a cutting height of up to 100mm
• stable and precisely guided rip fence
• strong grey cast iron table for long life
• Table extension and table widening

Scope of delivery TS315F1600400V Holzmann sliding table saw incl. sizing table​

• Carbide circular saw blade Ø315mm,
• Outriggers,
• Table extension,
• Table extension rip fence,
• telescopic boom stop,
• Trimming shoe,
• Hold-down device,
• Sliding stick and sliding wood

Technical data TS315F1600400V Holzmann sliding table saw incl. sizing table​

• Motor power S1 in W: 2800
• voltage: 400V / 50Hz
• Motor power S6 in W: 3920

• Table size in mm: 800 x 365
• Table height in mm: 850
• Table extension in mm: 350 x 365
• Table extension in mm: 800 x 540
• Format sliding table in mm: 238 x 1600
• Suction connection in mm: 100
• Installation dimensions in mm: 3000 x 3200 x 1200
• Gross weight in kg: 187

• max. cutting height 90° in mm: 100
• max. cutting height 45° in mm: 70
• max. trimming length in mm: 1400

• Saw blade (/hole) in mm: 315 (/30)
• Saw blade speed in min-1: 4000

• Sound power level in dB(A): 103
• Sound pressure level in dB(A): 89.5
