ELMAG INDUSTRIE 1000/330 HD Universal lathe
ELMAG INDUSTRIE 1000/330 HD Universal lathe
ELMAG INDUSTRIE 1000/330 HD Universal lathe

ELMAG INDUSTRIE 1000/330 HD Universal lathe

Product No.:
88164
2-4 days 2-4 days (abroad may vary)
  • Spare parts supply
  • Top quality
  • Happy customers
  • Secure payment
  • Authorized dealers

Delivery: If you need the item very urgently, please ask in advance for the exact delivery time.

Weight:
3000 kg per piece
46.726,90 EUR

19% VAT excl. Shipping costs

Ask about product
Description

Product highlights ELMAG INDUSTRIE 1000/330 HD universal lathe​

  • The INDUSTRIE 330 HD universal lathes are the right answer when it comes to the precise machining of extra heavy, large machine, steel, tank construction and casting mould parts. With four top models in this powerful machine class, ELMAG® offers a perfect selection.
    A super-strong drive unit provides 7,500 watts of power for an easy-to-switch high-performance spindle gear with 12 clockwise or counter-clockwise speed settings. Oil-pressure lubrication ensures maximum precision and smooth running of the turning spindle. All gear wheels are made of
    hardened chrome-nickel steel, are precision-ground, particularly durable and smooth-running.

  • Super-hard, precision-ground prismatic guides (> HB 400) carry a heavy tool slide according to the requirements. Thanks to a rapid traverse motor, it can be moved effortlessly and quickly. The traction spindle is engaged by an adjustable slipping clutch. The massive tailstock is moved by means of a crank drive and has an adjustment device for the quill feed. The INDUSTRIE 330-HD models are very well equipped for plug&play start-up, including a quick-change steel holder set for rapid tool changes and a digital position display from SINO for maximum precision and efficiency in single-part and series production.

  • SPECIAL

    - Electromagnetic rotary spindle foot brake
    - Longitudinal and cross slide with rapid traverse drive
    - Lead screw with adjustable slipping clutch
    - Lead screw with overload protection
    - Tool slide with central lubrication
    - Longitudinal stop for automatic stop
    - Coolant system with return, tank in machine base
    - With digital position indicator SINO

  • STANDARDS

    - Heavy cast iron machine bed, good vibration damping
    - Demountable bridge
    - Prismatic guides hardened (> HB 400) and precision ground
    - Rotating spindle hardened and precision ground, high concentricity, adjustable precision bearings
    - Turning spindle with oil pressure lubrication
    - Smooth-running turning spindle and feed gear with oil bath
    - Gear wheels made of chrome-nickel steel, hardened and precision-ground
    - Shaft for right-hand and left-hand rotation of the spindle
    - Feed reverser
    - Tool slide with lock nut and central lubrication
    - Precise slide guides, adjustable
    - Solid tailstock with tapered rotation and crank drive
    - Lathe accuracy according to DIN 8606

  • Standard equipment ELMAG INDUSTRIE 1000/330 HD universal lathe​

  • - Digital position indicator SINO SDS6-3V
    - RÖHM three-jaw lathe chuck Ø 315 mm
    - Four-jaw faceplate chuck Ø 400 mm
    - Clamping disc Ø 610 mm
    - 2 fixed centre points
    - Travelling centre point MK 5
    - Running steady rest
    - Steady rest
    - Quick-change steel holder set, 5-piece MC
    - Threaded clock and change gear set
    - LED machine lamp
    - Emergency stop button / zero-voltage trigger
    - Lathe chuck guard with safety switch
    - Underframe / chip tray / splashboard
    - Tool kit / Operating instructions / CE

  • Special accessories ELMAG INDUSTRIE 1000/330 HD Universal lathe​

  • - Insert turning tool set 25 x 25 mm, 7-piece
    - Insert set 7 pieces for turning tool set 25 x 25 mm
    - Turning tool set "Camlock" 25 x 25 mm, 7 pieces
    - Parting-off toolholder 25 x 25 mm, length 150 mm
    - Knife for parting-off holder 25 x 25 mm

  • Technical data ELMAG INDUSTRIE 1000/330 HD Universal lathe

  • Peak width1,000 mm
  • Peak height330 mm
  • Turning diameter over bed660 mm
  • Turning diameter over carriage420 mm
  • Turning diameter without bridge870 mm
  • Machine bed width400 mm
  • Bridge length230 mm
  • Cross slide travel360 mm
  • Top slide travel145 mm
  • Turning tool cross-section, max.25 x 25 mm
  • Lathe chuck mountingD1 - 8
  • Spindle mounting (turning spindle)MK 6
  • Spindle bore105 mm
  • Speed36 - 1,600 rpm rpm
  • Speed steps12
  • Longitudinal feeds(52) 0.063 - 2 mm/rev
  • Cross feeds(52) 0.027 - 1.07 mm/rev
  • Metric thread(22) 1 -14 mm
  • metric modular thread(18) 0.5 - 7 mm
  • inch threads, G(28) 1/4 - 56 G/'
  • Inch modular thread, G(24) 1/4 - 56 G/'
  • Lead screw pitch12 mm
  • Lead screw diameter40 mm
  • Spindle sleeve mountingMK5
  • Quill diameter75 mm
  • Quill travel150 mm
  • Motor power7,500 W
  • Rapid traverse drive250 W
  • Coolant pump125 W
  • Mains connection400/50-60 V/Hz
  • Length (total)2,500 mm
  • Width (total)1,100 mm
  • Height (total)2,450 mm
  • Weight3,000 kg
Highest quality machines from ELMAG
Benefit from a 2-year ELMAG guarantee
Accessories for ELMAG machines on request
