Bernardo pull, cut and double mitre saw ZKG 305 D
Properties Bernardo pull, cut and double mitre saw ZKG 305 D
- Suitable for cutting wood, coated panels, plastics and non-ferrous metals
- Complete with linear laser device to show exact position of sawblade
- Precise double column guide for smooth and even travel
- Powerful motor for top results even at long operations
- Table extensions on both sides ensures optimal workpiece support
- Includes integrated cutting depth stop for groove cutting
- Sawblade gets covered automatically when lifting the sawblade
- Useable for straight-, grade-, mitre and double mitre cuts
- Equipped with dust port directly at saw unit
- Easy and quick sawblade change with locking device
- To guarantee for safe transport column can be locked into position
- Rotary disc with rests at 0º / 15º / 22.5º / 31.6º and 45º
- Low weight allows for easy transport
- Easy to read scales for mitre and bevel angles and cutting width
Standard accessories Bernardo pull, cut and double mitre saw ZKG 305 D:
- Carbide sawblade 305 x 3,0 x 25,4 mm / 80T
- Table extension
- Extractable stop fence
- Linear laser device
- Waste bag
- Downholder
Technical specifications Bernardo pull, cut and double mitre saw ZKG 305 D:
| Sawblade diameter x bore | 305 x 25,4 mm |
| No load speed | 4800 rpm |
| Cutting capacity |
|
| Straight cuts at 90° / 90° | 340 x 95 mm |
| Mitre cuts at 45° right / left | 240 x 95 mm |
| Grade cuts at 45° left* | 340 x 55 mm |
| Grade cuts at 45° right* | 340 x 55 mm |
| Double mitre cuts at 45° left | 240 x 55 mm |
| Double mitre cuts at 45° right | 240 x 55 mm |
| Motor power | 1,6 kW (2,2 HP) |
| Voltage | 230 V |
| Machine dimension (W x D x H) | 860 x 900 x 680 mm |
| Weight approx. | 28 kg |
* saw unit
